onsemi SS14
- Part No.:
- SS14
- Manufacturer:
- onsemi
- Category:
- Single Diodes
- Package:
- DO-214AC, SMA
- Datasheet:
-
SS14.pdf
- Description:
- DIODE SCHOTTKY 40V 1A DO214AC
- Quantity:
- Payment:

- Shipping:

SS14 Specifications
- Attributes
- Property Value
- Manufacturer:
- onsemi
- Series:
- -
- Package/Case:
- DO-214AC, SMA
- Packaging:
- Tape & Reel (TR)
- Product Status:
- Active
- Technology:
- Schottky
- Voltage - DC Reverse (Vr) (Max):
- 40 V
- Current - Average Rectified (Io):
- 1A
- Voltage - Forward (Vf) (Max) @ If:
- 500 mV @ 1 A
- Speed:
- Fast Recovery =< 500ns, > 200mA (Io)
- Reverse Recovery Time (trr):
- -
- Current - Reverse Leakage @ Vr:
- 200 µA @ 40 V
- Capacitance @ Vr, F:
- -
- Grade:
- -
- Qualification:
- -
- Mounting Type:
- Surface Mount
- Supplier Device Package:
- DO-214AC (SMA)
- Operating Temperature - Junction:
- -65°C ~ 125°C
