TDK Corporation CK45-E3DD103ZYGNA
- Part No.:
- CK45-E3DD103ZYGNA
- Manufacturer:
- TDK Corporation
- Category:
- Ceramic Capacitors
- Package:
- Datasheet:
-
CK45-E3DD103ZYGNA.pdf
- Description:
- CAP CER 10000PF 2KV RADIAL
- Quantity:
- Payment:

- Shipping:

CK45-E3DD103ZYGNA Specifications
- Attributes
- Property Value
- Manufacturer:
- TDK Corporation
- Series:
- CK45
- Packaging:
- Bulk
- Product Status:
- Active
- Capacitance:
- 10000 pF
- Tolerance:
- -20%, +80%
- Voltage - Rated:
- 2000V (2kV)
- Temperature Coefficient:
- E
- Operating Temperature:
- -25°C ~ 105°C
- Features:
- High Voltage
- Ratings:
- -
- Applications:
- General Purpose
- Failure Rate:
- -
- Mounting Type:
- Through Hole
- Package / Case:
- Radial, Disc
- Size / Dimension:
- 0.571" Dia (14.50mm)
- Height - Seated (Max):
- 0.728" (18.50mm)
- Thickness (Max):
- -
- Lead Spacing:
- 0.295" (7.50mm)
- Lead Style:
- Formed Leads - Kinked
