DC Brushless Fans (BLDC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Voltage - Rated | Size / Dimension | Width | Air Flow | Static Pressure | Bearing Type | Fan Type | Features | Noise | Power (Watts) | RPM | Termination | Ingress Protection | Operating Temperature | Approval Agency | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
06015KA-24J-AL-00FAN AXIAL 60X15MM 24VDC TERM |
2,319 |
|
Datasheet |
06015KA | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 15.00mm | 6.7 CFM (0.188m³/min) | 0.030 in H2O (7.5 Pa) | Ball | Tubeaxial | Auto Restart, Locked Rotor Sensor | 19.0dB | 960 mW | 1800 RPM | 3 Terminals | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
|
06015KA-12N-AT-00FAN AXIAL 60X15MM 12VDC TERM |
4,973 |
|
Datasheet |
06015KA | Bulk | Active | 12VDC | Square - 60mm L x 60mm H | 15.00mm | 18.3 CFM (0.512m³/min) | 0.200 in H2O (49.8 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 34.0dB | 1.92 W | 4600 RPM | 3 Terminals | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
|
06015KA-12M-AT-00FAN AXIAL 60X15MM 12VDC TERM |
4,905 |
|
Datasheet |
06015KA | Bulk | Active | 12VDC | Square - 60mm L x 60mm H | 15.00mm | 15.9 CFM (0.445m³/min) | 0.160 in H2O (39.8 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 31.0dB | 1.56 W | 4100 RPM | 3 Terminals | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
|
06015KA-12L-AT-00FAN AXIAL 60X15MM 12VDC TERM |
4,608 |
|
Datasheet |
06015KA | Bulk | Active | 12VDC | Square - 60mm L x 60mm H | 15.00mm | 14.1 CFM (0.395m³/min) | 0.130 in H2O (32.4 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 28.0dB | 1.08 W | 3600 RPM | 3 Terminals | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
|
06015KA-24L-AL-00FAN AXIAL 60X15MM 24VDC TERM |
3,325 |
|
Datasheet |
06015KA | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 15.00mm | 14.1 CFM (0.395m³/min) | 0.130 in H2O (32.4 Pa) | Ball | Tubeaxial | Auto Restart, Locked Rotor Sensor | 28.0dB | 1.44 W | 3600 RPM | 3 Terminals | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
|
06015KA-24K-AL-00FAN AXIAL 60X15MM 24VDC TERM |
1,801 |
|
Datasheet |
06015KA | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 15.00mm | 11.6 CFM (0.325m³/min) | 0.090 in H2O (22.4 Pa) | Ball | Tubeaxial | Auto Restart, Locked Rotor Sensor | 25.0dB | 1.44 W | 3100 RPM | 3 Terminals | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
|
06015KA-12J-AL-00FAN AXIAL 60X15MM 12VDC TERM |
2,033 |
|
Datasheet |
06015KA | Bulk | Active | 12VDC | Square - 60mm L x 60mm H | 15.00mm | 6.7 CFM (0.188m³/min) | 0.030 in H2O (7.5 Pa) | Ball | Tubeaxial | Auto Restart, Locked Rotor Sensor | 19.0dB | 480 mW | 1800 RPM | 3 Terminals | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
|
06015KA-24M-AL-00FAN AXIAL 60X15MM 24VDC TERM |
3,760 |
|
Datasheet |
06015KA | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 15.00mm | 15.9 CFM (0.445m³/min) | 0.160 in H2O (39.8 Pa) | Ball | Tubeaxial | Auto Restart, Locked Rotor Sensor | 31.0dB | 1.68 W | 4100 RPM | 3 Terminals | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
|
06015KA-24L-AT-00FAN AXIAL 60X15MM 24VDC TERM |
3,701 |
|
Datasheet |
06015KA | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 15.00mm | 14.1 CFM (0.395m³/min) | 0.130 in H2O (32.4 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 28.0dB | 1.44 W | 3600 RPM | 3 Terminals | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
|
06015KA-12J-AT-00FAN AXIAL 60X15MM 12VDC WIRE |
2,228 |
|
Datasheet |
06015KA | Bulk | Active | 12VDC | Square - 60mm L x 60mm H | 15.00mm | 6.7 CFM (0.188m³/min) | 0.030 in H2O (7.5 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 19.0dB | 500 mW | 1800 RPM | 3 Wire Leads | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
|
06015KA-12K-AT-00FAN AXIAL 60X15MM 12VDC WIRE |
3,037 |
|
Datasheet |
06015KA | Bulk | Active | 12VDC | Square - 60mm L x 60mm H | 15.00mm | 11.6 CFM (0.325m³/min) | 0.090 in H2O (22.4 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 25.0dB | 840 mW | 3100 RPM | 3 Wire Leads | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
|
06015KA-24J-AT-00FAN AXIAL 60X15MM 24VDC WIRE |
3,500 |
|
Datasheet |
06015KA | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 15.00mm | 6.7 CFM (0.188m³/min) | 0.030 in H2O (7.5 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 19.0dB | 1 W | 1800 RPM | 3 Wire Leads | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
|
06015KA-24M-AT-00FAN AXIAL 60X15MM 24VDC WIRE |
3,388 |
|
Datasheet |
06015KA | Bulk | Active | 24VDC | Square - 60mm L x 60mm H | 15.00mm | 15.9 CFM (0.445m³/min) | 0.160 in H2O (39.8 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 31.0dB | 1.68 W | 4100 RPM | 3 Wire Leads | - | 14 ~ 140°F (-10 ~ 60°C) | - | - |
|
CFM-8038S-240-449-20FAN AXIAL 80X37.6MM 24VDC WIRE |
1,443 |
|
Datasheet |
CFM-80S | Box | Active | 24VDC | Square - 80mm L x 80mm H | 37.60mm | 49.4 CFM (1.38m³/min) | 0.370 in H2O (92.2 Pa) | Sleeve | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 45.0dB(A) | 5.76 W | 4000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CFM-8038S-130-387-20FAN AXIAL 80X37.6MM 12VDC WIRE |
4,052 |
|
Datasheet |
CFM-80S | Box | Active | 12VDC | Square - 80mm L x 80mm H | 37.60mm | 37.1 CFM (1.04m³/min) | 0.210 in H2O (52.3 Pa) | Sleeve | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 38.7dB(A) | 2.88 W | 3000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CBM-9330C-230-439-22DC BLOWER, 92.3 X 92.6 X 30 MM, |
2,930 |
|
Datasheet |
CBM-93C | Box | Active | 24VDC | Rectangular/Rounded - 92.5mm L x 92.3mm H | 29.50mm | 18.6 CFM (0.521m³/min) | 0.840 in H2O (209.2 Pa) | omniCOOL™ Magnetic Sleeve | Blower | Auto Restart, PWM Control, Speed Sensor (Tach) | 43.9dB(A) | 5.04 W | 3000 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CBM-9330C-130-439-22DC BLOWER, 92.3 X 92.6 X 30 MM, |
1,497 |
|
Datasheet |
CBM-93C | Box | Active | 12VDC | Rectangular/Rounded - 92.5mm L x 92.3mm H | 29.50mm | 18.6 CFM (0.521m³/min) | 0.840 in H2O (209.2 Pa) | omniCOOL™ Magnetic Sleeve | Blower | Auto Restart, PWM Control, Speed Sensor (Tach) | 43.9dB(A) | 4.08 W | 3000 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
DC0802012M2B-2T2FAN 80X20MM 12VDC MOLEX 22-01-10 |
1,692 |
|
Datasheet |
- | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | 20.00mm | 36.6 CFM (1.03m³/min) | 0.150 in H2O (37.3 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 34.0dB(A) | 2.16 W | 3100 RPM | 2 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-7020V-140-375FAN AXIAL 70X20MM 12VDC WIRE |
2,973 |
|
Datasheet |
CFM-70V | Tray | Obsolete | 12VDC | Square - 70mm L x 70mm H | 20.00mm | 37.1 CFM (1.04m³/min) | 0.210 in H2O (52.3 Pa) | omniCOOL™ Magnetic Sleeve | Tubeaxial | Auto Restart | 37.5dB(A) | 2.7 W | 4000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | 0.176 lb (79.83 g) |
|
|
CFM-7020V-143-400FAN AXIAL 70X20MM 12VDC WIRE |
4,787 |
|
Datasheet |
CFM-70V | Tray | Obsolete | 12VDC | Square - 70mm L x 70mm H | 20.00mm | 40.0 CFM (1.12m³/min) | 0.240 in H2O (59.8 Pa) | omniCOOL™ Magnetic Sleeve | Tubeaxial | Auto Restart | 40.0dB(A) | 3.18 W | 4300 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | 0.176 lb (79.83 g) |
